Basic Installation 3-17MN1902
3.5.3 Motor cable pin configuration - Baldor linear motors
The following table shows the pin colors used in a typical Baldor linear motor cable set, part
number AY1763A00:
Signal na me
Motor cable wire color
Motor U Black
Motor V Red
Motor W White
Motor ground Green
Thermal switch Blue
Thermal switch Orange
Signal na me Hall c a ble wire color
Hall 1 (U) Wh ite
Hall 2 (V) Red
Hall 3 (W) Black
Hall ground Green
Hall +5VDC Brown
