103R5900102 /11 ClickShare CX-20
5.19 LAN Settings, EAP-TTLS security mode
About EAP-TTLS
EAP-TTLS (Tunneled Transport Layer Security) is an EAP implementation by Juniper networks. It is designed
to provide authentication that is as strong as EAP-TLS, but it does not require each user to be issued a
certificate. Instead, only the authentication servers are issued certificates. User authentication is performed by
password, but the password credentials are transported in a securely encrypted tunnel established based
upon the server certificates.
User authentication is performed against the same security database that is already in use on the corporate
LAN: for example, SQL or LDAP databases, or token systems. Since EAP-TTLS is usually implemented in
corporate environments without a client certificate we have not included support for this. If you prefer using
client certificates per user we suggest using EAP-TLS.
How to setup EAP-TTLS
1. Select Authentication Mode EAP-TTLS.
Image 5–32 EAP-TTLS
2. Fill out the Domain and Identity.
Domain The company domain for which you are enrolling, should match with the one
defined in your Active Directory.
Identity Identity of the user account in the Active Directory which will be used by the
ClickShare Buttons to connect to the corporate network.
3. Enter the Password.
The corresponding password for the identity that you are using to authenticate on the LAN network. Per
Base Unit each Button will use the same identity and password to connect to the corporate network.
4. Optionally, upload the CA certificate.
The following formats are allowed:
• .pem
• .cer
• .crt
• .pb7 (Base64 encoded DER)
