3.6 Network deployment requirements
General
This topic contains recommendations for integrating our device into your enterprise network. A detailed
overview is given in terms of minimal requirements and required ports and firewall rules needed to be
configured to make the specific function work.
Base Unit: first-time setup
• Activation and update: for this action, similar to the auto-update functionality described below, an
outbound TCP connection on port 443 is required towards update.cmp.barco.com and assets.cloud.barco.
com.
• Connection to XMS Cloud for activating SmartCare and XMS Cloud functionality: TCP Port 443 outbound
to *.azure-devices.net, *.core.windows.net and global.azure-devicesprovisioning.net.
The first-time setup requires a laptop with access to:
• XMS Cloud: outbound TCP Port 443 to xms.cloud.barco.com
• MyBarco portal: outbound TCP Port 443 to *.barco.com (login/xms.cloud.barco.com).
• (Optional) Web Configurator of the device: TCP ports 80 and 443 to the Base Unit or ability to connect
directly to the Base Unit’s Wi-Fi.
Overview of the required ports
Open the following ports on your network to ensure that you can share content via ClickShare:
Sender/Receiver Ports
ClickShare Button (wireless
presentation)
TCP 2345, 6544
UDP
ClickShare Desktop and Mobile
Apps (wireless presentation)
TCP 6541-6545
UDP 5353, 1900
Additional ports for Wireless
Conferencing (Button or Desktop
App)
TCP 1235, 9999
UDP 1234
AirPlay TCP 4100-4200, 7000, 7100, 47000
UDP 4100-4200, 5353
Google Cast TCP 8008, 8009, 9080
UDP 1900, 5353, 32768, 61000
5
Miracast MS-MICE TCP 7236, 7250
UDP 7236
ClickShare Configurator TCP 80, 443
UDP n/a
XMS Cloud TCP 443
XMS Edge TCP 4003
Auto-update TCP 80, 443
UDP n/a
CX-20 Installation
5. Google Cast will pick a random UDP port above 32768 to facilitate video streaming.
