133R5900102 /11 ClickShare CX-20
5.41 Reset to factory defaults
About the reset
When applying a reset to factory defaults, the device settings are reverted to the factory defaults. Additionally,
the Base Unit will be removed from the organization account in XMS cloud and the first time setup procedure
will be initiated, as if the device came out of the box.
The unit needs to be connected to the internet to complete the first time setup.
How to reset
1. Log in to the Configurator.
2. Click Support & Updates → Troubleshoot.
Image 5–61 Factory reset
3. Click Reset to factory defaults.
The following message is displayed: “This action will remove all settings of the Base Unit and replace them
with the default settings. Are you sure you want to continue?”
4. If you want to continue, click Yes, remove all settings otherwise click No, I changed my mind.
When yes is clicked, the system starts a reboot.
CX-20 Configurator
