4. Lamp & lamp house
2. R emove the anode wire lug (reference 1 image 4-7) from the anode s ocket. Use for that an Allen key.
Tip: Place the flat washer (reference 2 im age 4-7) and bolt back on its place after the lug is rem oved
Note: The most r ecent Lamp Houses for the DP2K -23B makes it possible to remove the anode socket together with the x enon
lamp from the Lamp House. The anode socket can be release from the xenon lamp once the xenon lamp is safely
sheltered in its protective container or wrapped in a protective cloth.
1
2
3
1
2
3
Image 4-7
3. R emove the hexagon s ocket head cap screw (reference 9) which fasten the cathode of the xenon lamp. Us e a 5 mm Allen
wrench.
Note: The cathode wire remains in its position after the s crew (reference 9) and washer (reference 10) are removed.
9
10
Image 4-8
Cathode fixation
4. R elease the four quarter turn screws (reference 2 imag e 4-9) of the UV blocker assembly a s illustrated. Make sure that the a node
support rem ains in its position while re leasing the screws.
Caution: Ensure that you w ear protective clothing, a full face shield and protective gloves.
2
Image 4-9
5. Support the xenon lamp inside the Lamp House with one hand while rem oving the UV blocker assem bly from the lamp house.
Note that some xenon lamps are installed w ith an anode adaptation bushing (reference 12 image 4-10).
Warning: Supporting the xenon lamp with o ne hand to prevents it from bumping against the chassis of the L amp House.
R59770495 DP2K-23B 30/04/2010
