Programming
5-39
HYGROPHIL® F 5673 Operating manual, Software version 1.8.x, 387896MDHEN(14.06.2013)
Edit a curve
● Choose the curve to be changed and touch the „Edit“ key.
Then you can change the name of the curve or edit points (add, delete or
edit pairs of variates) as described above.
Delete a curve
● Choose the curve you want to delete and touch the “Delete” key.
If you confirm the safety warning the selected curve will be deleted.
5.6.12 Offset
Various operating conditions or measurement tasks may necessitate an off-
set setting on the evaluation unit HYGROPHIL
®
F 5673. A constant shift of
the wave length over the entire operating range is then implemented for
each measurement.
N.B.: At a gas temperature of 30°C, this shift has a linear effect on the dis-
played measured value within the dew-point range –40...+20 °C DT. Outside
this range the offset correction has a greater effect on the displayed meas-
ured value on account of the sensor characteristic.
