BARTEC BENKE HYGROPHIL F 5673 - 1.4.2 CPU plug-in unit type 5673-113; 1.4.3 Power supply plug-in unit DC 10..36 V type 5673-108; 1.4.4 Power supply plug-in unit AC 100..240 V type 5673-109

System description
1-12
HYGROPHIL® F 5673 Operating manual, Software version 1.8.x, 387896MDHEN(14.06.2013)
1.4.2 CPU plug-in unit type 5673-113
Electrical data
Operating voltage CPU
5.5 V ± 2 %
Power consumption
800 mA
Fuse of battery
3.5 A
Interfaces
USB 2.0 Host
OHCI
Ethernet
100 MBit
Serial interfaces
5x up to 115200 Bit/s, 3.3 V LVTTL
2x up to 460800 Bit/s, 3.3 V LVTTL
Elektronics
Realtime clock
32.768 kHz (battery buffered)
Ambient conditions
Operating temperature
- 10 … + 50 °C
Storage temperature
- 20 … + 70 °C
Climatic class
JWF in accordance with DIN 40040
Protection type
IP00 in accordance with DIN 40050
1.4.3 Power supply plug-in unit DC 10..36V
type 5673-108
Electrical data
Input voltage
DC 10...36 V, fuse 6.3 A (T)
Output voltage
5,5 V 3.2 A short-circuit-proof
24 V 1.2 A short-circuit-proof
10 V max. 100 mA
Maximum output power
60 W
Ambient conditions
Operating temperature
- 10 … + 50 °C
Storage temperature
- 20 … + 70 °C
1.4.4 Power supply plug-in unit AC 100..240V
type 5673-109
Electrical data
Input voltage
AC 100...240 V, fuse 3.15 A (MT)
Output voltage
5.5 V 3.2 A short-circuit-proof
24 V 1.2 A short-circuit-proof
10 V max. 100 mA
Maximum output power
110 VA
Ambient conditions
Operating temperature
- 10 … + 50 °C
Storage temperature
- 20 … + 70 °C
