Programming
5-1
HYGROPHIL® F 5673 Operating manual, Software version 1.8.x, 387896MDHEN(14.06.2013)
5 Programming
Various operating parameters and functions can be programmed in order to
operate the HYGROPHIL
®
F 5673 humidity measurement system. You can
adjust the measurement system to the given operating requirements and the
system environment.
An overview of the menu structure in the programming mode can be found in
section 5.5.
5.1 General instructions
In the programming mode, the humidity measurement goes on in the back-
ground.
After the return to the display mode, the indication is updated in accordance
with the new programming.
The following sections describe the principles of working with the different
menus and the parameter settings.
The keys can be assigned different functions whose current meaning is
marked by icons.
All keys are touch-sensitive, i.e. you need not press them but only touch
them.
Icon
Meaning
Effect
Open
The marked menu is opened,
for a marked parameter, an entry dialog or a selection dialog is opened.
Quit menu
You quit the menu that is open at present and change over to the super or-
dinate menu.
Abort
You quit the menu that is open at present and change over to the super or-
dinate menu.
Settings/entries already carried out are rejected.
Correct
In an entry dialog the character left to the cursor is deleted.
Take over, store
The selected setting of a parameter is confirmed.
You quit the menu that is open at present.
All settings/entries (also of the subordinate menus) are taken over and
stored.
All changes will only be stored if you quit the menu by means of this
key!
