1.4.5 Analog I/O Ex type 5673-114
Electrical data
Operating voltage for CPU
DC 5.5 V ± 2 % 200 mA, fuse 400 mA
Operating voltage for sensor supply
DC 24 V ± 5 %, max. 480 mA, fuse 1 A
PT-100 [EEx ia]
Type
Pt-100 (4 wires), l 1 mA -50...+100 °C
Resolution
0.005 °C (16 bit)
Separation
galvanically isolated
Analog Output [EEx ia]
Current range
0/4-20 mA
resolution
0.0003 mA
Separation
galvanically isolated
Sampling
Max. 10 /s
Aktive
Load max. 500 Ω
Passive
U
max
:36 V, U
min
at 20 mA: 8 V
Analog Input [EEx ia]
Quantity
2
Input current
4...20 mA
Resolution
0.005 mA
Separation
galvanically isolated
Sampling
Max. 10 /s
output voltage V+1 and V+2
DC 24 V ±10% max. 30 mA, short-circuit-proof
Ambient conditions
Operating temperature
- 10 … + 50 °C
Storage temperature
- 20 … + 70 °C
