1.4.6 Interface module type 5673-110
Electrical data
Operating voltage for CPU
DC 5,5 V ± 2 %
Operating voltage for interfaces
DC 24 V ± 5 %
3 x Analog output
Current range
0/4 – 20 mA, galvanically isolated, source
Resolution
0,0003 mA
Apparent ohmic resistance
< 800 Ω
Accuracy
± 0.15 %
Temperature drift
<0.001 mA/°C
2 x RS485
Functionality
Modbus
Output voltage for each interface
24 V ± 5 %, max. 50 mA
2 x RS232
Functionality
Logging
Output voltage for each interface
24 V ± 5 %, max. 50 mA
Profibus
Functionality
Profibus DB (Slave)
Output voltage for each interface
5V ± 2 %, max. 50 mA
2 x USB
Functionality
Standard USB interface
Only for service and maintenance purposes
Ambient conditions
Operating temperature
- 10 … + 50 °C
Storage temperature
- 20 … + 70 °C
