1.4 Technical data
1.4.1 Evaluation unit F 5673
Evaluation unit
Display ranges
(not the measuring range)
Measurement variable
Lower range limit
Upper range limit
Vol% [%]
0
100
PPM [ppm]
0
25000
DT [°C,°F,K]
-100
100
FP [°C,°F,K]
-100
100
MC [mg/m
3
],
[lb/MMscF]
0
30000
VP [hPa]
0
250
TT [°C,°F,K]
-50
100
SP [bar,PSI,..]
0
250
WL [nm]
780
830
Auxiliary variables
The temperature (TT) at the measuring point is measured via a sensor inte-
grated in the humidity sensor or entered by hand. The pressure (SP) is
measured via a 4...20 mA signal from an external pressure transmitter or
entered by hand. CO
2
-content (0...100%) is measured via a 4...20 mA-
signal or entered by hand.
Measurement channels
1, 2 or 3
Measuring rate
Max. 3 measurements / minute per channel
Inputs per measurement channel
- Light waveguide port for optical humidity sensor
- 9-pole D-SUB plug for data memory with sensor characteristic
- Clamp-type terminal for PT 100 measurement sensor in sensor head
- Clamp-type terminal for signal from a pressure transmitter for absolute
pressure (4...20 mA)
- Clamp-type terminal for CO
2
content (4...20 mA)
all inputs Ex ia, galvanically isolated
Analog outputs per measurement
channel
Clamp-type terminal 0/4...20 mA, EEx ia, galvanically isolated
Source and sink
Resolution 0.0003 mA
Max. load: 500 Ω
Accuracy: 0.03 mA
Temperature drift: <0.001 mA/ °C
Interfaces
RS 232, modbus, profibus
Display
Graphic display 320 x 240 dots
Keyboard
Red backlit touch-screen
Auxiliary energy
DC 10...36 V max. 60 W (Si 6.3 A T)
AC 100...240 V max. 110 VA (Si 3.15 A MT)
Ambient conditions
Permissible working temperature: 0...+50 °C
Permissible storage temperature: -20...+60 C
Climatic category: IWI according to DIN 40040
Dimensions (WxHxD)
483 x 192 x 212
Approvals
ATEX, CSA, GOST
Weight
approx. 8.5 kg
