416 9424200994 Rev N
Step 7: Verify the pickup and dropout accuracy at 120 Vac for a pickup setting of 42 V (126 Vac on test
set) and 70 Vac for a pickup setting of 25 V (75 Vac on test set) as listed in Table 164. Record
the results.
Step 8: (Optional.) Repeat steps 1 through 7 for the B-phase and C-phase voltage inputs.
Step 9: (Optional.) Repeat steps 1 through 8 for settings group 1, 2, and 3.
Step 10: (Optional.) Repeat steps 1 through 9 for 59X-2, 59X-3, and 59X-4.
Timing Verification (V2 Mode)
Step 1: Use BESTCOMSPlus to open the Protection, Voltage, Overvoltage (59X-1) screen and send
the first row of test settings in Table 165 to the BE1-11g for settings group 0.
Table 165. Timing Test Settings (V2 Mode)
Pickup Setting
Time Delay
42 V
2,000 ms
42 V
5,000 ms
42 V
10,000 ms
Step 2: Prepare to monitor the 59X-1 timings. Timing accuracy is verified by measuring the elapsed
time between a sensing voltage change and OUT1 closing.
Step 3: Connect and apply a 120 Vac, single-phase voltage source to terminals C13 (A-phase) and C16
(neutral).
Step 4: Step the voltage up to 130 volts. Measure the time delay and record the result.
Step 5: Repeat step 4 for the 5,000 ms and 10,000 ms time delay settings of Table 165. Record the
results.
Step 6: (Optional.) Repeat steps 1 through 5 for settings group 1, 2, and 3.
Step 7: (Optional.) Repeat steps 1 through 6 for 59X-2, 59X-3, and 59X-4.
Pickup Verification (Vx Fundamental Mode)
Step 1: Use BESTCOMSPlus to send the operational settings in Table 166 to the BE1-11g. Reset all
targets.
Table 166. Operational Settings (Vx Fundamental Mode)
Setting
Value
BESTCOMSPlus Screen
Description
Aux VT Ratio
1
System Parameters, Sensing
Transformers
Sets auxiliary VT ratio to 1
Aux VT
Connection
AN
System Parameters, Sensing
Transformers
Sets auxiliary VT connection to
AN
Element Mode
Vx
Fundamental
Protection, Voltage,
Overvoltage (59X-1)
Enables 59X-1 function for Vx
Fundamental mode
Timing Mode
Definite
Protection, Voltage,
Overvoltage (59X-1)
Selects definite timings
59X-1 AUX
Enabled
Target Configuration, Targets
Enables Vx Fundamental target
for 59X-1
Step 2: Use BESTCOMSPlus to configure the BESTlogicPlus programmable logic shown in Figure 289.
• Blocking is disabled.
• OUT1 closes for 59X-1 Trip.
• OUT2 closes for 59X-1 Pickup.
• Fault recording is enabled.
Auxiliary Overvoltage (59X) Test BE1-11g
