9400200990 Rev I DGC-2020 Installation 6-5
Table 6-5. Sender Input Terminals
Terminal Description
8 (OIL) Oil pressure sender input
9 (FUEL) Fuel level sender input
10 (COOLANT) Coolant temperature sender input
11 (SENDER COM) Sender return terminal
Magnetic Pickup Input
The magnetic pickup input accepts a speed signal over the range of 3 to 35 volts, peak and 32 to 10,000
hertz. Magnetic pickup input terminals are listed in Table 6-6.
Table 6
-6. Magnetic Pickup Input Terminals
Terminal Description
31 (MPU+) Magnetic pickup positive input
32 (MPU–) Magnetic pickup return input
Contact Sensing Inputs
Contact sensing inputs consist of 1 emergency stop input and 16 programmable inputs.
The emergency stop input is intended for use with a normally closed switch and recognizes an
emergency stop input when the short-circuit across the input is removed.
The programmable inputs accept normally open, dry contacts. Terminal 2 (BATT–) serves as the common
return line for the programmable inputs. Information about configuring the programmable inputs is
provided in Section 4, BESTCOMSPlus Software.
Contact sensing input terminals are listed in
Table 6-7.
Table 6
-7. Contact Sensing Inputs
Terminal Description
2 (BATT–) Common return line for programmable contact inputs
15 (INPUT 16) Programmable contact input 16
16 (INPUT 15) Programmable contact input 15
17 (INPUT 14) Programmable contact input 14
18 (INPUT 13) Programmable contact input 13
19 (INPUT 12) Programmable contact input 12
20 (INPUT 11) Programmable contact input 11
21 (INPUT 10) Programmable contact input 10
22 (INPUT 9) Programmable contact input 9
23 (INPUT 8) Programmable contact input 8
24 (INPUT 7) Programmable contact input 7
25 (INPUT 6) Programmable contact input 6
26 (INPUT 5) Programmable contact input 5
27 (INPUT 4) Programmable contact input 4
28 (INPUT 3) Programmable contact input 3
29 (INPUT 2) Programmable contact input 2
30 (INPUT 1) Programmable contact input 1
46 (ESTOP)
47 (ESTOP)
Emergency stop contact input
