Basler DGC-2020 User Manual

9400200990 Rev I DGC-2020 Modbus™ Communication B-21
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
40737 Commission Start Month 1-12 R W month
40738 Commission Start Day 1-31 R W day
40739 Commission Start Year 0-99 R W year
40740-41 Cumulative Run Hours x 60 0-4294967295 R W DP hours
40742-43
Cumulative Loaded Run Hours x
60
0-4294967295 R W DP hours
40744-45
Cumulative Unloaded Run Hours x
60
0-4294967295 R W DP hours
40746 Start Count 0-65535 R W
40747 Session Start Month 1-12 R W month
40748 Session Start Day 1-31 R W day
40749 Session Start Year 0-99 R W year
40750-51 Session Run Hours x 60 0-4294967295 R W DP hours
40752-53 Session Loaded Run Hours x 60 0-4294967295 R W DP hours
40754-55 Session Unloaded Run Hours x 60 0-4294967295 R W DP hours
Canbus ECU
40758 ECU Control Output Select 0-1 R W
0 = fuel solenoid relay,
1 = pre-start relay
40759 ECU Pulsing Enable 0-1 R W
0 = pulsing is enabled,
1 = pulsing is disabled
40760 MDEC Alarms 0-65535 R
b0 = High Charge Air Temp,
b1 = High Oil Temp,
b2 = High Coolant Temp,
b3 = Low Aftercooler Level,
b4 = Low Fuel Delivery Press,
b5 = Low Oil Press,
b6 = Overspeed,
b7 = Combined Red,
b8-b15 UNASSIGNED
40761 MDEC Pre-alarms 0-65535 R
b0 = High ECU Temp,
b1 = High Oil Temp,
b2 = High Intercooler Temp,
b3 = High Charge Air Temp,
b4 = High Coolant Temp,
b5 = Shutdown Override,
b6 = High Fuel Rail Press,
b7 = Low Fuel Rail Press,
b8 = Low Coolant Level,
b9 = Low Charge Air Pressure,
b10 = Low Fuel Deliv Pressure,
b11 = Low Oil Pressure,
b12 = Combined Yellow,
b13-b15 UNASSIGNED
Current Parameter Table
The DGC-2020 maps all non-legacy parameters into the Holding Register address space (42000 and
above). Query address N will access the Holding Register N+1. Data Format is Long Integer type data
unless identified otherwise in the Data Format column. See Table B-4.
Table B-4. Current Parameter Table
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
BREAKER MANAGEMENT
42000 Gen Breaker Configured 0-1 R
0 = NOT Configured,
1 = Configured
42002 Gen Breaker Open Pulse Time 1-80 R W milliseconds * 10
42004 Gen Breaker Close Pulse Time 1-80 R W milliseconds * 10
42006 Gen Breaker Contact Type 0-1 R W
0 = Pulse,
1 = Continuous
42008 Gen Breaker Close Time 0-800 R W milliseconds in increments of 5
