B-22 DGC-2020 Modbus™ Communication 9400200990 Rev I
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
42010 RESERVED
42012 Mains Breaker Configured 0-1 R W
0 = NOT Configured,
1 = Configured
42014 Mains Breaker Open Pulse Time 1-80 R W milliseconds * 10
42016 Mains Breaker Close Pulse Time 1-80 R W milliseconds * 10
42018 Mains Breaker Ouput Continuous 0-1 R W
0 = Pulse,
1 = Continuous
42020 Mains Breaker Close Time 0-800 R W milliseconds in increments of 5
42022 RESERVED
42024 Synchronizer Type 1-2 R W
1 = Anticipatory,
2 = Phase Lock Loop
42026 RESERVED
42028 Slip Frequency 5-50 R W (milliseconds * 10) in increments of 5
42030 Breaker Closing Angle 30-200 R W Degrees / 10 in increments of 10
42032 Regulation Offset 20-150 R W (% / 10) in increments of 5
42034 Vgen > Vbus 0-1 R W
0 = Disable
1 = Enable
42036 Fgen > Fbus 0-1 R W
0 = Disable
1 = Enable
42038-40 RESERVED
42042 Breaker Close Wait Time 0.1 - 600.0 R W FP
seconds in
increments of
0.1
42044 Sync Time Delay 0.1 - 0.8 R W FP
seconds in
increments of
0.1
42046 Sync Fail Time Delay 0.1 - 600.0 R W FP
seconds in
increments of
0.1
42048 Mains Fail Transfer Enable 0-1 R W
0 = Disabled,
1 = Enabled
42050 Gen Breaker Status 0-1 R
0 = Open,
1 = Closed
42052 Mains Breaker Status 0-1 R
0 = Open,
1 = Closed
42054-60 FUTURE USE
42062 Dead Bus Close Enable 0-1 R W
0 = Disable
1 = Enable
42064-248 FUTURE USE
SYNCHRONIZER BIAS CONTROLS
42250-92 RESERVED
42294-348 FUTURE USE
42350 Speed Droop Gain R W
42354 Speed Trim Enable 0-1 R W
0 = Disable
1 = Enable
42358-498 FUTURE USE
42500 AVR Correction Pulse Width 0-999 R W milliseconds * 100 in increments of 1
42502 AVR Correction Pulse Interval 0-999 R W milliseconds * 100 in increments of 1
42504 AVR Bias Contact Type 0-1 R W
0 = Continuous,
1 = Proportional
42506 RESERVED
42508 Governor Correction Pulse Width 0-999 R W milliseconds * 100 in increments of 1
42510 Governor Correction Pulse Interval 0-999 R W milliseconds * 100 in increments of 1
42512 Governor Bias Contact Type 0-1 R W
0 = Continuous,
1 = Proportional
42514 RESERVED
42516-748 FUTURE USE
BUS CONDITION DETECTION
42750 Gen Sensing Dead Bus Pickup 0-4800 R W (Volts / 10) in increments of 10
42752 Gen Sensing Dead Bus Time Delay 1-6000 R W (milliseconds * 100) in increments of 1
42754 RESERVED
