Basler DGC-2020 User Manual

9400200990 Rev I DGC-2020 Modbus™ Communication B-23
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
42756
Gen Sensing Stable Undervoltage
Pickup
100-12000 R W (Volts / 10) in increments of 10
42758
Gen Sensing Stable Undervoltage
Dropout
100-12000 R W (Volts / 10) in increments of 10
42760
Gen Sensing Stable Overvoltage
Pickup
100-12000 R W (Volts / 10) in increments of 10
42762
Gen Sensing Stable Overvoltage
Dropout
100-12000 R W (Volts / 10) in increments of 10
42764
Gen Sensing Stable
Underfrequency Pickup
4600-6400 R W (Hz / 100) in increments of 5
42766
Gen Sensing Stable
Underfrequency Dropout
4600-6400 R W (Hz / 100) in increments of 5
42768
Gen Sensing Stable Overfrequency
Pickup
4600-6400 R W (Hz / 100) in increments of 5
42770
Gen Sensing Stable Overfrequency
Dropout
4600-6400 R W (Hz / 100) in increments of 5
42772 Gen Sensing Fail Time Delay 1-6000 R W (milliseconds * 100) in increments of 1
42774 Gen Sensing Stable Time Delay 1-6000 R W (milliseconds * 100) in increments of 1
42776 RESERVED
42778 Bus Sensing Dead Bus Pickup 0-4800 R W (Volts / 10) in increments of 10
42780 Bus Sensing Dead Bus Time Delay 1-6000 R W (milliseconds * 100) in increments of 1
42782 RESERVED
42784
Bus Sensing Stable Undervoltage
Pickup
100-12000 R W (Volts / 10) in increments of 10
42786
Bus Sensing Stable Undervoltage
Dropout
100-12000 R W (Volts / 10) in increments of 10
42788
Bus Sensing Stable Overvoltage
Pickup
100-12000 R W (Volts / 10) in increments of 10
42790
Bus Sensing Stable Overvoltage
Dropout
100-12000 R W (Volts / 10) in increments of 10
42792
Bus Sensing Stable
Underfrequency Pickup
4600-6400 R W (Hz / 100) in increments of 5
42794
Bus Sensing Stable
Underfrequency Dropout
4600-6400 R W (Hz / 100) in increments of 5
42796
Bus Sensing Stable Overfrequency
Pickup
4600-6400 R W (Hz / 100) in increments of 5
42798
Bus Sensing Stable Overfrequency
Dropout
4600-6400 R W (Hz / 100) in increments of 5
42800 Bus Sensing Fail Time Delay 1-6000 R W (milliseconds * 100) in increments of 1
42802 Bus Sensing Stable Time Delay 1-6000 R W (milliseconds * 100) in increments of 1
42804 RESERVED
42806-3432 FUTURE USE
SENDERS
43434
Coolant Temperature Sender Fail
Configuration Type
-1, 0, 1 R W
0 = None
1 = Alarm
2 = Pre-Alarm
43436
Coolant Temperature Sender Fail
Activation Delay
50-300 R W Minutes in increments of 5
43438
Oil Pressure Sender Fail
Configuration Type
-1, 0, 1 R W
0 = None
1 = Alarm
2 = Pre-Alarm
43440
Oil Pressure Sender Fail Activation
Delay
0-300 R W Seconds in increments of 1
43442
Fuel Level Sender Fail
Configuration Type
-1, 0, 1 R W
0 = None
1 = Alarm
2 = Pre-Alarm
43444
Fuel Level Sender Fail Activation
Delay
0-300 R W Seconds in increments of 1
43446
Voltage Sensing Fail Configuration
Type
-1, 0, 1 R W
0 = None
1 = Alarm
2 = Pre-Alarm
43448
Voltage Sensing Fail Activation
Delay
0-300 R W Seconds in increments of 1
