B-24 DGC-2020 Modbus™ Communication 9400200990 Rev I
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
43450-498 FUTURE USE
SYSTEM CONFIGURATION AND STATUS
43500 Rated Volts 1-999 R W Volts in increments of 1
43502 Pre-Start Contact Config 0-1 R W
0 = Open After Disconnect
1 = Closed While Running
43504 System Units 0-1 R W
0 = English
1 = Metric
43506 Battery Volts 0-1 R W
0 = 12V
1 = 24V
43508 Off Mode Status 0-1 R
0 = Disable
1 = Enable
43510 Run Mode Status 0-1 R
0 = Disable
1 = Enable
43512 Auto Mode Status 0-1 R
0 = Disable
1 = Enable
43514 Virtual Input 1 Status 0-1 R
0 = Disable
1 = Enable
43516 Virtual Input 2 Status 0-1 R
0 = Disable
1 = Enable
43518 Virtual Input 3 Status 0-1 R
0 = Disable
1 = Enable
43520 Virtual Input 4 Status 0-1 R
0 = Disable
1 = Enable
43624 EPS Low Line Scale Factor 0-3 R W Increments of 0.001
43626 Rated Power Factor -1 to 1 R W Increments of 0.001
43628 Prestart Rest Configuration 0-2 R W
0 = Off During Rest
1 = On During Rest
2 = Preheat before Crank
43630 Oil Pressure Crank Disconnect 0-1 R W
0 = Disable
1 = Enable
43632 Crank Disconnect Pressure 3-150 R W Increments of 1
43634 Crank Disconnect Pressure in KPA 21-1034 R W Increments of 1
43636-748 FUTURE USE
CONTROL
43750 Emergency Stop 0-1 R W
A value of 1 will invoke the Emergency
Stop
43752 Remote Start 0-1 R W
A value of 1 will invoke the Remote
Start
43754 Remote Stop 0-1 R W
A value of 1 will invoke the Remote
Stop
43756 Run Mode 0-1 R W A value of 1 will invoke the Run Mode
43758 Off Mode 0-1 R W A value of 1 will invoke the Off Mode
43760 Auto Mode 0-1 R W A value of 1 will invoke the Auto Mode
43762 RESERVED
43764 Gen Breaker Open 0-1 R W A value of 1 will open the Gen Breaker
43766 Gen Breaker Close 0-1 R W A value of 1 will close the Gen Breaker
43768 Mains Breaker Open 0-1 R W A value of 1 will open the Mains
43770 Mains Breaker Close 0-1 R W A value of 1 will close the Mains
43772 RESERVED
43774 Virtual Input 1 Close 0-1 R W
A value of 1 will close the Virtual Input 1
Switch
43776 Virtual Input 1 Open 0-1 R W
A value of 1 will open the Virtual Input 1
Switch
43778 Virtual Input 2 Close 0-1 R W
A value of 1 will close the Virtual Input 2
Switch
43780 Virtual Input 2 Open 0-1 R W
A value of 1 will open the Virtual Input 2
Switch
43782 Virtual Input 3 Close 0-1 R W
A value of 1 will close the Virtual Input 3
Switch
43784 Virtual Input 3 Open 0-1 R W
A value of 1 will open the Virtual Input 3
Switch
