9400200990 Rev I DGC-2020 Modbus™ Communication B-25
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
43786 Virtual Input 4 Close 0-1 R W
A value of 1 will close the Virtual Input 4
Switch
43788 Virtual Input 4 Open 0-1 R W
A value of 1 will open the Virtual Input 4
Switch
43790-998 FUTURE USE
PROTECTION
44000-34 RESERVED
44036-48 FUTURE USE
44050 DHCP Enabled 0-1 R
0 = Disabled
1 = Enabled
44052 Active IP Address R
44054 Gateway IP Address R
44056 Subnet Mask R
44058-248 FUTURE USE
44250 3 Phase Overcurrent Pickup (51-1)
18-118 1A
90-7750 5A
R W (Sec Amps / 100) in increments of 1
44252
3 Phase Overcurrent Time Dial (51-
1)
0-99 R W (Units / 10) in increments of 1
44254 3 Phase Overcurrent Curve (51-1) 0-16 R W
0 = S1 Curve
1 = S2 Curve
2 = L1 Curve
3 = L2 Curve
4 = D Curve
5 = M Curve
6 = I1 Curve
7 = I2 Curve
8 = V1 Curve
9 = V2 Curve
10 = E1 Curve
11 = E2 Curve
12 = A Curve
13 = B Curve
14 = C Curve
15 = G Curve
16 = F Curve
44256
3 Phase Overcurrent Alarm
Configuration (51-1)
0-2 R W
0 = None
1 = Alarm
2 = Pre-Alarm
44258 1 Phase Overcurrent Pickup (51-1)
18-118 1A
90-7750 5A
R W (Sec Amps / 100) in increments of 1
44260
1 Phase Overcurrent Time Dial (51-
1)
0-99 R W (Units / 10) in increments of 1
44262 1 Phase Overcurrent Curve (51-1) 0-16 R W
0 = S1 Curve
1 = S2 Curve
2 = L1 Curve
3 = L2 Curve
4 = D Curve
5 = M Curve
6 = I1 Curve
7 = I2 Curve
8 = V1 Curve
9 = V2 Curve
10 = E1 Curve
11 = E2 Curve
12 = A Curve
13 = B Curve
14 = C Curve
15 = G Curve
16 = F Curve
44264
1 Phase Overcurrent Alarm
Configuration (51-1)
0-2 R W
0 = None
1 = Alarm
2 = Pre-Alarm
44266 Phase Imbalance Pickup 5-100 R W Volts in increments of 1
