9400200990 Rev I DGC-2020 Modbus™ Communication B-33
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
44828 Local Input Metering 0 - 4294967295 R
Bit 0 = Input 1
Bit 1 = Input 2
Bit 2 = Input 3
Bit 3 = Input 4
Bit 4 = Input 5
Bit 5 = Input 6
Bit 6 = Input 7
Bit 7 = Input 8
Bit 8 = Input 9
Bit 9 = Input 10
Bit 10 = Input 11
Bit 11 = Input 12
Bit 12 = Input 13
Bit 13 = Input 14
Bit 14 = Input 15
Bit 15 = Input 16
44830 Local Output Metering 0 - 4294967295 R
Bit 0 = Output 1
Bit 1 = Output 2
Bit 2 = Output 3
Bit 3 = Output 4
Bit 4 = Output 5
Bit 5 = Output 6
Bit 6 = Output 7
Bit 7 = Output 8
Bit 8 = Output 9
Bit 9 = Output 10
Bit 10 = Output 11
Bit 11 = Output 12
44832 Status Metering 0 - 4294967295 R
Bit 0 = EPS Supplying Load
Bit 1 = Single Phase Override
Bit 2 = Single Phase AC Override
Bit 3 = Low Line Override
Bit 4 = Auto Transfer Switch
Bit 5 = Battle Override
Bit 6 = Grounded Delta Override
Bit 7 = Mains Breaker Closed
Bit 8 = Gen Breaker Closed
44834 Hours Until Maintenance 0-5000 R Hours in increments of 1
44836 Cum. Total Engine Run Hrs. 0 - 99,999 R Hours in increments of 1
44838 Cum. Total Engine Run Min. 0-60 R Minutes in increments of 1
44840 Cum. Loaded Engine Run Hrs. 0 - 99,999 R Hours in increments of 1
44842 Cum. Loaded Engine Run Min. 0-60 R Minutes in increments of 1
44844 Cum. Unloaded Engine Run Hrs. 0 - 99,999 R Hours in increments of 1
44846 Cum. Unloaded Engine Run Min. 0-60 R Minutes in increments of 1
44848 Cum. Total kW-Hrs 0 - 4294967295 R KW-Hrs in increments of 1
44850 FUTURE USE
44852 Commission Date Month 1-12 R Month in increments of 1
44854 Commission Date Day 1-31 R Day in increments of 1
44856 Commission Date Year 0 - 4294967295 R Year in increments of 1
44858 Session Total Engine Run Hrs. 0 - 99,999 R Hours in increments of 1
44860 Session Total Engine Run Min. 0-60 R Minutes in increments of 1
44862 Session Loaded Engine Run Hrs. 0 - 99,999 R Hours in increments of 1
44864 Session Loaded Engine Run Min. 0-60 R Minutes in increments of 1
44866 Session Unloaded Engine Run Hrs. 0 - 99,999 R Hours in increments of 1
44868 Session Unloaded Engine Run Min. 0-60 R Minutes in increments of 1
44870 Session kW-Hrs 0 - 4294967295 R KW-Hours
44872
Cumulative Number of Engine
Starts
0 - 4294967295 R Quantity in increments of 1
44874 Session Start Date Month 1-12 R Month in increments of 1
44876 Session Start Date Day 1-31 R Day in increments of 1
44878 Session Start Date Year 0 - 4294967295 R Year in increments of 1
