B-34 DGC-2020 Modbus™ Communication 9400200990 Rev I
Holding
Register
Parameter Range
Read/Write
Supported
Data
Format
Units
44880 Generator Status 0 - 11 R
0 = RESET State
1 = READY State
2 = CRANKING State
3 = RESTING State
4 = RUNNING State
5 = ALARM State
6 = PRESTART State
7 = COOLING State
8 = CONNECTING State
9 = DISCONNECT State
10 = PULSING State
11 = UNLOADING State
44882-918 FUTURE USE
44920-48 RESERVED
44950 Global Alarm 0-1 R
0 = No system alarms in effect
1 = System alarm(s) in effect
44952 Global Pre-Alarm 0-1 R
0 = No system pre-alarms in effect
1 = System pre-alarm(s) in effect
44954
Local Configurable Inputs Pre-
Alarm Bits
R Bit 0 = Input 1, Bit 1 = Input 2, etc.
44956
Local Configurable Inputs Alarm
Bits
R Bit 0 = Input 1, Bit 1 = Input 2, etc.
44958 Configurable Elements Status Bits R
Bit 0 =Config Element 1, Bit 1 = Config
Element 2, etc.
44960
Configurable Elements Pre-Alarm
Bits
R
Bit 0 = Config Element 1, Bit 1 = Config
Element 2, etc.
44962 Configurable Elements Alarm Bits R
Bit 0 = Config Element 1, Bit 1 = Config
Element 2, etc.
44964 Remote Inputs Status Bits R
Bit 0 = Remote Input 17, Bit 2 = Remote
Input 18, etc.
44966 Remote Outputs Status Bits R
Bit 0 = Remote Output 13, Bit 1 =
Remote Output 14, etc.
44970
Remote Configurable Inputs Pre-
alarm Bits
R
Bit 0 = Remote Input 17, Bit 1 = Remote
Input 18, etc.
44972
Remote Configurable Inputs Alarm
Bits
R
Bit 0 = Remote Input 17, Bit 1 = Remote
Input 18, etc.
44974-98 RESERVED R
45000 ECU Lamp Status 0 - 4294967295 R
Bit 24 = Malfunction
Bit 27 = Stop
Bit 28 = Warning
Bit 31 = Protect
45002 Number of DTC’s 0 - 4294967295 R
Quantity in increments of 1
