Baumer Description | 3
V2 | OX100 Operating Manual 19
Holding Reg-
isters
The following table provides an overview of the Index Commands Holding Registers. These
can be reached with functions 03/06/16.
Address Data element Data type Access Description
0
(1 Regis-
ter)
Request parametrisation
mode.
UInt16 Write Request parametrisation
mode by writing a random
value.
1
(1 Regis-
ter)
Exit parametrisation mode. UInt16 Write Exit active parametrisation
mode by writing a random
value.
501
(1 Regis-
ter)
Load parameter setup num-
ber.
UInt16 Write Load a previously
parametrised parameter
setup.
Input Regis-
ters
The following tables provide an overview of Index Commands Input Registers. These can be
reached with function 04.
This function code will read 1 to 125 related input registers in a remote device. The PDU query
(Process Data Unit) specifies the start register address and the number of registers. PDU regis-
ter addressing starts with zero. For this reason, input registers 1-16 are addressed as 0-15.
Address Data element Data type Access Offset Description
0...32
(33 Register)
Vendor info String[65] Read 0 Manufacturer
name
Address Data element
Data
type Access Offset Description
40...88
(49 Regis-
ter)
Device info Read Exit active parametrisation
mode by writing a random
value.
String[9] 0...3 Product ID
4 High byte
String[65] 4 Low byte Sensor type
5...36
String[20] 37...46 Serial number
String[2] 47...48 Padding
