3 | Description Baumer
20 Operating Manual OX100 | V2
Address Data element
Data
type Access Offset Description
200...223
(24 Regis-
ter)
All Measure-
ment Values
(32 Bit)
Read
Status UInt16 0 Status
Bit 0 Parametrisation mode is ac-
tive.
Bit 1 Time is synchronised with NTP
server.
Bit 2 Valid values (measured values
allow for interpretation).
Bit 3 Alarm is active.
Quality UInt8 1 Quality information on the current mea-
sured values.
0 OK
1 Weak signal.
2 No signal.
Output UInt8 2 Outputs
Bit 0 Status of binary output 1.
Bit 1 Status of binary output 2.
Measured
value 1
Float32 Measured value parametrised in ad-
vance on the web interface.
3 Low 2Bytes
4 High 2Bytes
Measured
value 2
Float32 Measured value parametrised in ad-
vance on the web interface.
5 Low 2Bytes
6 High 2Bytes
Measured
value 3
Float32 Measured value parametrised in ad-
vance on the web interface.
7 Low 2Bytes
8 High 2Bytes
Measured
value 4
Float32 Measured value parametrised in ad-
vance on the web interface.
9 Low 2Bytes
10 High 2Bytes
Measured
value 5
Float32 Measured value parametrised in ad-
vance on the web interface.
11 Low 2Bytes
12 High 2Bytes
Measured
value 6
Float32 Measured value parametrised in ad-
vance on the web interface.
13 Low 2Bytes
