Baumer Description | 3
V2 | OX100 Operating Manual 21
Address Data element
Data
type Access Offset Description
14 High 2Bytes
Measured
value 7
Float32 Measured value parametrised in ad-
vance on the web interface.
15 Low 2Bytes
16 High 2Bytes
Measurement
rate
Float32 Measurement rate
17 Low 2Bytes
18 High 2Bytes
Time stamp (s) UInt32 Value of the time stamp (s) of the most
recent measured values.
19 Low 2Bytes
20 High 2Bytes
Time stamp
(µs)
UInt32 Value of the time stamp (µs) of the
most recent measured values.
21 Low 2Bytes
22 High 2Bytes
UInt16 23 reserved
Address Data element Data type Access Offset Description
401
(1 Regis-
ter)
Active Parameter Setup Number. UInt8 Read 0
Address Data element
Data
type Access Offset Description
2500...251
5
(16 Regis-
ter)
All Measure-
ment Values
(16 Bit)
Read
Status UInt16 0 Status
Bit 0 Parametrisation mode is ac-
tive.
Bit 1 Time is synchronised with NTP
server.
Bit 2 Valid values (measured values
allow for interpretation).
Bit 3 Alarm is active.
Quality UInt8 1 Quality information on the current mea-
sured values.
0 OK
1 Weak signal.
2 No signal.
