3 | Description Baumer
22 Operating Manual OX100 | V2
Address Data element
Data
type Access Offset Description
Output UInt8 2 Outputs
Bit 0 Status of binary output 1.
Bit 1 Status of binary output 2.
Measured
value 1
I
Int16 3 Measured value parametrised in ad-
vance on the web interface.
Measured
value 2
I
Int16 4 Measured value parametrised in ad-
vance on the web interface.
Measured
value 3
I
Int16 5 Measured value parametrised in ad-
vance on the web interface.
Measured
value 4
I
Int16 6 Measured value parametrised in ad-
vance on the web interface.
Measured
value 5
I
Int16 7 Measured value parametrised in ad-
vance on the web interface.
Measured
value 6
I
Int16 8 Measured value parametrised in ad-
vance on the web interface.
Measured
value 7
I
Int16 9 Measured value parametrised in ad-
vance on the web interface.
Measurement
rate (Hz)
II
Int16 10 Measurement rate
Time stamp (s) UInt32 Value of the time stamp (s) of the most
recent measured values.
11 Low 2Bytes
12 High 2Bytes
Time stamp
(µs)
UInt32 Value of the time stamp (µs) of the
most recent measured values.
13 Low 2Bytes
14 High 2Bytes
UInt16 15 reserved
I
Divide the received measured value by 100 to obtain the result in the physical measuring
unit.
II
Divide the received measuring rate by 10 to obtain the measuring rate in Hz.
