Baumuller b maXX 5500 - Page 207

Installation
Instruction handbook b maXX BM5500, BM5600, BM5700
Document No.: 5.13008.10
207
of 314
7
X6 Analog inputs/
outputs
There are two analog inputs and outputs available.
Pin assignment X6
Pin No. Assignment
1 Analog input 1 +
2 Analog input 2 +
3 Ground
4 Analog output 1 +
5 Analog output 2 +
6 Analog output 1 -
7 Analog output 2 -
8 Analog output 1 -
9 Analog output 2 -
Inputs Resolution
12 bit
Type Differential input
Input resistance Approx. 50 k
Max. input current 200 µA
Sampling rate 5 µs
Input voltage +10 V to -10 V
Outputs Resolution 12 bit
Output voltage +10 V to -10 V
Max. output current 1 mA
Update rate 5 µs
Short-circuit-proof Limited, max. 10 s
