B-2 FLO-GARD 6301 DUAL CHANNEL VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-729
Pump Serial Number: _____________________________
Printed Name Signature Date
Tester: _____________________________ _____________________________ ____________
Reviewer (optional): _____________________________ _____________________________ ____________
Calibration Verification (Verification in Mode 2)
NORM and MIN Air Sensor Calibration with Primed Tubing
NORM
330-565
Val u e P u m p 1: Val u e P u mp 2 :
MIN Value Pump 1: Value Pump 2:
NORM and MIN Air Sensor Calibration with Air Filled Tubing
NORM
< 11
Val u e P u m p 1: Val u e P u mp 2 :
MIN Value Pump 1: Value Pump 2:
NORM and MIN Air Sensor Calibration with No Tube
NORM
< 11
Val u e P u m p 1: Val u e P u mp 2 :
MIN Value Pump 1: Value Pump 2:
FSR Verification with Pump Door Open
RIGHT
500-820
Val u e P u m p 1:
Val u e P u mp 2 :
LEFT Value Pump 1:
Val u e P u mp 2 :
FSR Verification with Pump Door Closed
RIGHT
500-820
Val u e P u m p 1:
Val u e P u mp 2 :
LEFT Value Pump 1:
Val u e P u mp 2 :
FSR Verification with Tubing Misloaded
RIGHT
450 or less
Val u e P u m p 1:
Val u e P u mp 2 :
LEFT Value Pump 1:
Val u e P u mp 2 :
Vcpu 472-579 Value Pump 1:
Val u e P u mp 2 :
