The individual characters are explained in the following table.
Character no.
Decimal
value
Status
Meaning
8
0 / 1
Alarm Integral 2 on/off
1
4
0 / 1
Alarm Integral 1 on/off
2
0 / 1
Alarm measured value 2 b on / off
1
0 / 1
Alarm measured value 1 (a) on / off
8
0 / 1
FIFO overwritten
4
0 / 1
Probe failure off / on
2
2
0 / 1
FIFO 75% full
1
0 / 1
Memory full
8
0 / 1
System test in progress
4
0 / 1
Clearance in progress
3
2
0 / 1
Measurement in progress
1
0 / 1
Background in progress
8
0 / 1
4
4
0 / 1
2
0 / 1
1 when data above measuring range 2
1
0 / 1
1 when data above measuring range 1
8
0 / 1
Mean value bit
4
0 / 1
Search measuring mode
5
2
0 / 1
Ratem measurement mode
1
0 / 1
C/T measurement mode
8
0 / 1
Beta channel invalid
4
0 / 1
Detector mode only b
6
2
0 / 1
Detector mode only a
1
0 / 1
Detector mode a/b
8
1 - 24
Detector number
4
7
2
1
8
8
4
2
1
9
8
0 / 1
4
0 / 1
2
0 / 1
Clearance: contaminated, no / yes
1
0 / 1
System test OK, no /yes
Byte 10 – 12 free
The order in the telegram is from left to right 1, 2, 3, 4; 5.
