4. MBR = channel of a processor
1,2,3 = digital inputs
1,2,3,4,5 = fault outputs
1.2 = analog outputs
5. TYPE = type of request
00 = not connected
01 = measured results
02 = measuring parameters
03 = execute action
6. ITM = element of a request, command
7. CSM = checksum
If empty, no check
8. MSK = data mask
for selection of very specific individual data, e.g. from the FIFO; not in operation.
11.5.3 Command Overview
The following commands can be sent from a host computer. The structure is as described above. Only the
content is displayed:
Comment:
If commands are sent with no parameters, the device answers with the parameters currently set.
If any command is sent with the TDV 0000, the device answers with its device identification. However, this
should only be done if only one device is connected to the bus, as all devices respond to this command.
