Berthold LB 134 - 11.8 Example of RS485 Network with Multiple LB 134 as Dose Rate Monitor

LB 134 11. Appendix
144
11.8 Example of RS485 Network with Multiple LB 134 as Dose Rate Monitor
RS485 to USB
or RS232 adapter
120 Ohm
120 Ohm
Earth (Ground)
Additional monitors (up to 31)
Connection boxes
Cable length: < 1000 m
Shielded
twisted pair cable
All measuring stations
local floating, not grounded
