Figure 6.34 Alarm settings
If the alarm is set to Acoustic or Optical/Acoustic, you will hear,
in addition to the visual alarm, an acoustic signal when the
threshold is exceeded. The respective threshold is stored spe-
cific to the nuclide or specific to the measurement mode in the
nuclide/measurement type table and can be edited.
6.13 Ticks
Here the measuring channel (radiation type) can be set in which
acoustic ticks are to be heard; for an alpha beta contamination
probe there are two entries. For a dose rate probe, only one
channel can be activated.
Figure 6.35: Selection of measuring channel for
acoustic indication of individual events
