CFX96 and CFX384 Systems Manual
15
Startup Wizard
The Startup Wizard automatically appears when CFX Manager software is first opened
(Figure 17). If it is not shown, click the Startup Wizard button on the main software window
toolbar.
Figure 17. Startup Wizard window.
Options in the Startup Wizard include the following:
Experiment Setup Open the Experiment Setup window to run an
experiment (page 21)
Protocol AutoWriter Open the Protocol AutoWriter window to create a new
protocol (page 37)
Select User Open the Select User window to change software
users (see “Log in or Select User” on page 121)
User Preferences Open the User Preferences window (page 121)
Help Open the software Help window for more information
about running PCR and real-time PCR
Table 8. Toolbar buttons in the main software window (continued)
Button Button Name Function

BIO RAD CFX96 Specifications

General

Temperature Uniformity	±0.4 °C
Software	CFX Maestro Software
Detection Method	Real-time PCR (qPCR)
Sample Capacity	96-well plate
Excitation Source	LED
Ramp Rate	Up to 5°C/sec
Heating Rate	5°C/sec
Sensitivity	Single copy detection
Power Requirements	100-240 V, 50/60 Hz
Temperature Range	0–100 °C
