BK Precision 9140 Series - Voltage Slew; Current Slew; On;Off Delay

Output Conguration 33
4.2.3 Voltage Slew
The rising voltage slew rate can be set in volts per second. The voltage slew range can be set from
0.001 V/s to 3200.0 V/s.
1. Press the button then use the soft key to select Output cong > Output Settings.
2. Select a desired channel to congure.
3. Select Voltage Slew and use the numeric keypad or rotary knob to adjust the slew rate value. Press
to conrm input.
4.2.4 Current Slew
The rising current slew rate can be set in amps per second. The current slew range can be set from
1 A/s to 800 A/s.
1. Press the button then use the soft key to select Output cong > Output Settings.
2. Select a desired channel to congure.
3. Select Next Pg. > Current Slew and use the numeric keypad or rotary knob to adjust the slew rate
value. Press to conrm input.
4.2.5 On/O Delay
A channel on or o delay in seconds can be applied to any channel. These delays can be set from
0.001 s to 3600.0 s.
1. Press the button then use the soft key to select Output cong > Output Settings.
2. Select a desired channel to congure.
3. Select Next Pg. > On Delay to set an on delay or O Delay to set an o delay.
4. Use the numeric keypad or rotary knob to adjust the delay value. Press to conrm input.
