BK Precision 9140 Series - Setting Voltage and Current

Basic Front Panel Operation 29
3.4 Setting Voltage and Current
Follow the steps below to set the output voltage or current. The values can be entered using the numeric
keypad or the rotary knob.
1. Using the keypad: Use the soft keys to select the channel VSET or ISET settings beneath channel
view on the display. Then use the numeric keypad to input the voltage or current value then press
to conrm.
2. Using the rotary knob: Use the soft keys to select the channel VSET or ISET settings beneath
the channel view on display. Then turn the knob clockwise to increment or counter-clockwise to
decrement the value.
a. Use the below the rotary knob to move the cursor. Press the knob in to conrm.
