Introduction 12
1.2 Contents
Please inspect the instrument mechanically and electrically upon receiving it. Unpack all items from the
shipping carton, and check for any obvious signs of physical damage that may have occurred during
transportation. Report any damage to the shipping agent immediately. Save the original packing carton
for possible future reshipment. Every power supply is shipped with the following contents:
• 1 x 9140 or 9141 Power Supply
• 1 x AC Power Cord
• 1 x Certicate of Calibration
• 1 x Test Report
Note:
Ensure the presence of all the items above. Contact
the distributor or B&K Precision if anything is missing.
1.3 Features
• Three independent galvanically isolated, oating output channels providing up to 100 W per channel
or 300 W total when combining all three channels
• High power density, compact 2U half-rack form factor
• Multi-ranging operation delivers rated power at various voltage/current combinations
• Combine outputs in parallel or series to increase current or voltage (up to 24 A or 180 V depending
on the model)
• Advanced list mode programming with internal storage for up to 10 list mode programs and list
sequencing capabilities
• Digital I/O block oers external triggering, voltage fault and remote inhibit capabilities
• Overvoltage (OVP), overcurrent (OCP), overtemperature (OTP), and includes a key-lock function
• NISPOM-compliant sanitization procedure to securely erase and return the instrument to factory
settings
