Calibration Adjustment Procedure 93
10.4 OCP Calibration Adjustment
For the over current protection calibration the instrument’s current must be calibrated.
To adjust the OCP calibration:
1. Enter the Calibration Menu
• Press the button, then use the soft key to select Utilities > Test/Admin > Security.
Use the numeric keypad to enter security code. See the subsection Security. Press the
button to enter the security menu.
2. Use the softkeys to select OCP > CH {1 |2 |3}.
3. Verify the correct channel is chosen.
• The upper left corner will display the chosen channel. OCP Calibration will have a frame with the
color corresponding to the chosen channel.
– Yellow = CH 1
– Blue = CH 2
– Orange = CH 3
4. Connect the DMM’s 10 A input to the power supply’s binding post corresponding to the selected
channel.
5. Use the softkey to select Start.
6. Calibration State will show as Busy. After a few seconds the calibration will be adjusted on its own.
7. Upon successfully completing the calibration adjustment a dierent channel can be selected.
8. Repeat steps 2 through 6 to calibrate the remaining channels.
