Utilities Menu 77
O
The inhibit input is ignored.
Latched
A logic-true transition signal will disable the power supply. The output will remain disabled.
Live
Power supply output follows the state of the inhibit signal. If the inhibit signal is true the output is disabled.
When it is false the output is enabled.
7.5 Test/Admin
7.5.1 Self Test
Run a Module test.
Press the button then use the soft key to select Utilities > Test/Admin > Self-Test > Start.
Figure 7.9 Self Test Complete
7.5.2 Security
The Security Settings are locked and can be accessed by entering the default code 77416699.
