BK Precision 9140 Series - List Mode; List Mode Setup and Editing

List Mode
The 9140 and 9141 are capable of storing up to 10 programmable lists in the internal memory. Each list
can have up to 100 congurable steps.
List memory is shareable across all 3 channels, allowing the channels to run the same list or dierent list
simultaneously.
If all ten list numbers are taken, a list can also be saved to a USB. Lists can be loaded from a USB,
allowing for a larger collection of programmed lists.
5.1 List Setup
Press the button then use the soft key to select List Setup.
Use the softkeys to select one of the channels CH1, CH2, or CH3.
Figure 5.1 List Setup
Use the softkeys to set the following parameters.
