Data Logger 62
• Remote: Select to receive a trigger from a remote interface.
Note:
For Digital IO and Remote the rst trigger will turn Data log on. A second trigger will begin data
recording. will be displayed on the top right when data is being logged. See 6.2.7
6.2.7 Datalog Start/Stop
Press the button then use the soft key to select Data logger > Datalog Start/Stop. Toggle to turn
datalog On/O.
will be displayed on the top right when data logger is on but not recording.
The command INIT:IMM:DLOG will turn on data logger.
For Digital IO press Datalog Start/Stop to turn data logger on.
will be displayed on the top right when data logger is recording.
The command TRIG:DLOG:IMM will begin the recording.
For Digital IO an input high signal to the set pin will turn data logger on.
If Trigger Source is set to manual pressing Datalog Start/Stop will start/stop recording without a second
signal.
