BK Precision 9140 Series - Polarity; Inhibit Mode

Utilities Menu 76
Fault Out
Enable a fault condition, which generates a protection fault signal on the digital port.
Dierent conditions such as over voltage, over current, or over temperature will generate a fault event.
The fault event will “disable” all outputs without turning them o.
The outputs are “disabled” by setting the outputs as low as possible.
7.4.1 Polarity
Default: Positive
Set polarity of selected pin.
Positive
A logic true signal is received as a voltage high.
Negative
A logic true signal is received as a voltage low.
7.4.1 Inhibit Mode
Receive an external input signal that controls the output state of all channels.
Default: O
To set Inhibit Mode:
1. Assign the inhibit In function to pin 3 by:
Press the button then use the soft key to select Utilities > I/O Cong > Digital I/O > Pin 3 >
Inhibit In.
2. Select Inhibit Mode: Press the button then use the soft key to select Utilities > I/O Cong >
Digital I/O > Inhibit Mode.
3. Select one of the following modes:
Note:
The following modes are only available for pin 3.
