Introduction
1.1 Product Overview
9140: 32 V / 8 A / 300 W 9141: 60 V / 4 A / 300 W
Figure 1.1 Front View
The 9140 Series triple output multi-range DC power supplies combine industry-leading power density
and performance with an extensive set of features in a compact 2U form factor.
Three isolated output channels each produce 100 W of clean power with exceptionally low ripple and
noise characteristics. Combine channels to output up to 300 W, distributing the power across all three
channels. Multiple outputs paired with advanced list mode programming, data logging, and protection
features make these power supplies suitable for a wide range of benchtop or test system applications.
Model 9140 9141
Voltage per Channel 0 to 32 V 0 to 60 V
Current per Channel 0 to 8 A 0 to 4 A
Maximum Power per Channel 100 W
Maximum Combined Power 300 W
Table 1.1 Models
