Data Logger 60
6.2.4 Log Data
Press the button then use the soft key to select Data logger > Next Pg. > Log Data.
Select data to be logged.
– All: Record both voltage and current output of all channels.
– Voltage: Record the voltage output of all channels.
– Current: Record the current output of all channels.
Figure 6.3 Log Data All
The data is recorded in the following order:
CH1 Voltage CH1 Current CH2 Voltage CH2 Current CH3 Voltage CH3 Current Status Code
Table 6.1 Data Order
