BK Precision 9140 Series User Manual

Basic Front Panel Operation 28
Time Scale
The time scale of each output can be set from 1 s/Div up to 10 min/Div.
1. While in Live Output Display use the softkeys to select Time Scale.
2. Use the rotary knob to navigate through the available scales.
Voltage Oset
A voltage oset can be added to each output. The oset can be set from 0 V up to 60.6 V on the 9141
and 0 V up to 32.2 V on the 9140.
1. While in Live Output Display use the softkeys to select Voltage Oset.
2. Select a channel to congure.
3. Use the rotary knob to navigate through the available scales.
Current Oset
A current oset can be added to each output. The oset can be set from 0 A up to 4.4 A on the 9141
and 0 A up to 8.8 A on the 9140.
1. While in Live Output Display use the softkeys to select Current Oset.
2. Select a channel to congure.
3. Use the rotary knob to navigate through the available scales.
3.3 Check Model and Firmware Version
The rmware version, model, and serial number can be veried by entering the security settings. Press
button then use the soft keys to select Utilities > Help > System Info to view model and rmware
information.
