BK Precision 9140 Series - Output Operating Modes

Output Conguration 34
4.3 Operating Mode and Coupling
Set the operation mode or coupling.
Press the button then use the soft key to select Output Cong > Op. Mode/Coupling > Operation
Mode.
4.3.1 Normal Mode
Sets operation mode to Normal.
Normal mode sets the instrument to operate as a true triple output power supply.
Press the button then use the soft key to select Output Cong > Op. Mode/Coupling >
Operation Mode > Normal.
9140 9141
Individual CH Individual CH
32 V 8 A 60 V 4 A
Figure 4.2 Normal Mode
