BOCA PRO16 Reference Guide
Dumb Mode Operation
Dumb Mode
Operation
RESET
MODE
RDL
AL
TEST
BUSY
OUT
TD
RD
OH
CD
AA
TR
1
2
3
TPI
MODE
MODE
MODE
V25b1
V25b2
A ANS
SMART
ASYNC
ANS
12345678
LEFT (V.25bis command set)
RIGHT (AT command set)
LEFT (V.25bis synch bit-oriented)
RIGHT (V.25bis character-oriented)
LEFT (Disable auto-answer)
RIGHT (Enable auto-answer)
LEFT (DUMB Mode)
RIGHT (SMART Mode)
LEFT (Synchronous Mode)
RIGHT (Asynchronous Mode)
LEFT (Originate Mode)
RIGHT (Answer Mode)
TRANSMIT DATA
RECEIVE DATA
OFF HOOK
CARRIER DETECT
AUTO ANSWER
TERMINAL READY
Indicates modem’s operating
mode (see chart on next page)
Test Pattern indicator. Also lights when modem
is being accessed by a Rack Controller
Restarts the modem
Allows selection of line speed when in Dumb mode
Remote Digital Loopback Test
Analog Loopback Test
Initiates test functions
Takes modem off-hook
*Switches 1and 2 reserved for future use.
