Operating Instructions ACTIVE06/07 99
06/07 Operating Instructions ACTIVE 99
Stopping Behavior
Stopping behavior 0
Free stopping
The inverter is disabled immediately. The drive deener-
gized immediately and coasts freely.
Stopping behavior 1
Stop
+ Switch off
The drive is brought to a standstill at the set deceleration.
As soon as the drive is at a standstill, the inverter is dis-
abled after a holding time. The holding time can be set via
the parameter
Holding Time 638.
Depending on the setting of the parameter
Starting Func-
tion
620, the Starting Current 623 is impressed or the
Starting Voltage 600 is applied for the duration of the
holding time.
Stopping behavior 2
Stop + Hold
The drive is brought to a standstill at the set deceleration
and remains permanently supplied with current.
Depending on the setting of the parameter
Starting func-
tion
620, the Starting Current 623 is impressed as from
standstill or the
Starting Voltage 600 is applied.
Stopping behavior 3
Stop + DC brakes
The drive is brought to a standstill at the set deceleration.
As from standstill, the direct current set via parameter
Braking Current 631 is impressed for the Braking Time
632.
Comply with the notes in chapter "DC brake".
Stopping behaviors 3, 6 and 7 are only available in the
configurations for sensor-less control.
Stopping behavior 4
Emergency stop
+ switch off
The drive is brought to a standstill at the emergency stop
deceleration. As soon as the drive is at a standstill, the
inverter is disabled after a holding time.
The holding time can be set via the parameter
Holding
Time
638. Depending on the setting of the parameter
Starting Function 620, the Starting Current 623 is im-
pressed as from standstill or the
Starting Voltage 600 is
applied.
Stopping behavior 5
Emergency stop +
Hold
The drive is brought to a standstill at the set emergency
stop deceleration and remains permanently supplied with
current.
Depending on the setting of the parameter
Starting Func-
tion
620, the Starting Current 623 is impressed as from
standstill or the
Starting Voltage 600 is applied.
Stopping behavior 6
Emergency stop +
Brake
The drive is brought to a standstill at the set emergency
stop deceleration. As from standstill, the direct current set
via parameter
Braking Current 631 is impressed for the
Braking Time 632.
Comply with the notes in chapter "DC brake".
Stopping behaviors 3, 6 and 7 are only available in the
configurations for sensor-less control.
Stopping behavior 7
Direct current brake
Direct current braking is activated immediately. The direct
current set with the parameter
Braking Current 631 is
impressed for the die
Braking Time 632.
Comply with the notes in chapter "DC brake".
Stopping behaviors 3, 6 and 7 are only available in the
configurations for sensor-less control.
Comply with the notes for controlling a mechanical brake in chapter 14.3.4 Open
brake.
