14.2.1 Analog Output MFO1A
By default, the multifunction output MFO1 is configured for the output of a pulse
width modulated output signal with a maximum voltage of DC 24 V.
The selected configuration determines which actual values can be selected for pa-
rameter
Analog Operation 553 of multifunction output 1.
Analog operation 553 Function
0 - Off Analog operation MFO1 is switched off.
1 - Abs. Fs
Absolute value of stator frequency 1,
0.00 Hz ...
Maximum Frequency 419.
2 -
Abs. Fs betw.
fmin/fmax
Absolute value of stator frequency,
Minimum Frequency 418 ... Maximum Fre-
quency
419.
3 - Abs. Speed Sensor 1
Absolute value of speed sensor signal 1,
0.00 Hz ...
Maximum Frequency 419.
7 - Abs. Actual Frequency
Absolute value of actual frequency,
0.00 Hz ...
Maximum Frequency 419.
20 - Abs. Iactive
Absolute value of current active current I
ACTIVE
,
0.0 A ... FU rated current.
21 - Abs. Isd
Abs. value of flux-forming current component,
0.0 A ... FU rated current.
22 - Abs. Isq
Abs. value of torque-forming current component,
0.0 A ... FU rated current.
30 - Abs. Pactive
Absolute value of current active power P
ACTIVE
,
0.0 kW ...
Rated Power 376.
31 - Abs. M
Absolute value of calculated torque M,
0.0 Nm ... rated torque.
32 -
Abs. Inside Tempera-
ture
Abs. value of measured inside temperature,
0 °C ... 100 °C.
33 -
Abs. Heat Sink Tem-
perature
Abs. value of measured heat sink temperature,
0 °C ... 100 °C.
40 -
Abs. Analog Input
MFI1A
Absolute signal value at analog input 1,
0.0 V ... 10.0 V.
50 - Abs. I
Absolute current value of the measured output cur-
rents,
0.0 A ... FU rated current.
51 - DC link voltage
DC link voltage U
d
,
0.0 V ... 1000.0 V.
52 - V
Output voltage V,
0.0 V ... 1000.0 V.
53 - Volume Flow
Absolute value of calculated volumetric flow
0.0 m
3
/h ... Nominal Volumetric Flow 397.
54 - Pressure
Absolute value of calculated pressure
0.0 kPa ...
Nominal Pressure 398.
101 to 133 Operation modes in analog operation with signs.
14.2.1.1 Output Characteristic
The voltage range of the output signal at multifunction output 1 can be adjusted. The
value range of the actual value selected via parameter
Analog Operation 553 is as-
signed to the value range of the output signal which is adjusted via the parameters
Voltage 100% 551 and Voltage 0% 552.
