9.3 Internal values

The following parameters are used for the internal processing of motor data. An ad-

justment is not necessary.

Parameter

No. Description No. Description

368 Internal value 01 705

Internal value 08

399

Internal value 02

706

Internal value 09

402

Internal value 03

707

Internal value 10

508

Internal value 04

708

Internal value 11

702

Internal value 05

709

Internal value 12

703

Internal value 06

745

Internal value 13

704

Internal value 07

798

Internal value 14

9.4 Speed sensor 1

The frequency inverters are to be adapted to the application depending on the re-

quirements. A part of the available

Configurations 30 demand continuous measure-

ment of the actual speed for the control functions and methods. The necessary con-

nection of an incremental speed sensor is done on the digital control terminals S5IND

(track A) and S4IND (track B) of the frequency inverter.

9.4.1 Operation mode speed sensor 1

Operation mode speed sensor 1 490 can be selected according to the connected in-

cremental speed sensor. A unipolar speed sensor is to be connected to the standard

control terminals.

Operation mode 490 Function

0 - Off

Speed measurement is not active; the digital inputs

are available for other functions.

1 – Single Evaluation

Two-channel speed sensor with recognition of direc-

tion of rotation via track signals A and B;

one signal edge is evaluated per division mark.

4 –

Quadruple

evaluation

Two-channel speed sensor with recognition of direc-

tion of rotation via track signals A and B;

four signal edges are evaluated per division mark.

11 –

Single evaluation

without sign

One-channel speed sensor via track signal A; the ac-

tual speed value is positive. One signal edge is evalu-

ated per division mark. The digital input S4IND is

available for further functions.

12 –

Double evaluation

without sign

One-channel speed sensor via track signal A; the ac-

tual speed value is positive. Two signal edges are

evaluated per division mark. The digital input S4IND is

available for further functions.

101 –

Single evaluation

inverted

Same as in operation mode 1. The actual speed value

is inverted. (Alternative to exchanging the track sig-

nals)

104 –

Quadruple evalua-

tion inverted

Same as in operation mode 4. The actual speed value

is inverted. (Alternative to exchanging the track sig-

nals)

111 –

Single evaluation

negative

Same as operation mode 11. The actual speed value is

negative.

112 –

Double evaluation

negative

Same as operation mode 12. The actual speed value is

negative.
