Operating Instructions ACTIVE 06/07126
126 Operating Instructions ACTIVE 06/07
The control unit keys have the following functions:
Key functions
â–² / â–¼
Increase / reduce frequency.
ENT Reversal of the direction of rotation independent of the control signal on
the terminals Clockwise S2IND or Anticlockwise S3IND.
ENT
(1 sec)
Save the selected function as default value. The direction of rotation is not
exchanged.
ESC Cancel function and return to the menu structure.
FUN Switch from internal set point inP to JOG frequency; the drive starts.
Release the key to switch to the sub-function and stop the drive.
RUN Start drive; alternative to control signal S2IND or S3IND.
STOP Stop drive; alternative to control signal S2IND or S3IND.
13.10.3 Controlling the Motor via the Control Unit
The parameter
Reference Frequency Source 475 enables the assignment of the refer-
ence value sources in the frequency reference value channel. Operation modes can be
set without the function "Motorpoti (KP)".
If an operation mode is selected without "Motorpoti (KP)", it is still possible to control
a connected motor via the keys of the KP 500 control unit.
The function is activated as described in "Control Unit KP500, Controlling the Motor via
the Control Unit".
The speed of the modification of the reference value is limited by the parameter
Ramp
Keypad-Motorpoti 473.
Parameter Settings
No. Description Min. Max. Fact. sett.
473 Ramp Keypad-Motorpoti 0.00 Hz/s 999.99 Hz/s 2.00 Hz/s
