Operating Instructions ACTIVE06/07 197
06/07 Operating Instructions ACTIVE 197
19 Error Protocol
The various control methods and the hardware of the frequency inverter include func-
tions which continuously monitor the application. The operational and error diagnosis
is facilitated by the information stored in the error protocol.
19.1 Error List
The last 16 fault messages are stored in chronological order and the
No. of Errors
362 shows the number of errors which have occurred since commissioning of the
frequency inverter. In the VAL menu branch of the control unit, the error code FXXXX
is displayed. The meaning of the error key is described in the following chapter "Error
Messages". Via the PC program, the number of operation hours (h), operation minutes
(m) and the fault message can additionally be read out. The current operating hours
can be read out via the
Operation Hours Counter 245. The fault report can be ac-
knowledged via the keys of the operating unit and according to the assignment
Error
Acknowledgment
103.
Error List
No. Description Function
310 Last Error hhhhh:mm ; FXXXX fault message.
311 Last Error but one hhhhh:mm ; FXXXX fault message.
312 to 325 Eerror 3 to error 16.
362 No. of errors occurred
Number of errors occurred after commissioning
of the frequency inverter.
The error and warning behavior of the frequency inverter can be set in various ways.
The automatic error acknowledgment enables acknowledgment of the faults Overcur-
rent F0500, Overcurrent F0507 and Overvoltage F0700 without intervention by an
overriding control system or the user. The
No. of self acknowledged Errors 363
shows the total number of automatic error acknowledgments.
Error List
No. Description Function
363 No. of acknowledgment Errors Total number of automatic error acknowledg-
ment with synchronization.
19.1.1 Error Messages
The error code stored following a fault comprises the error group FXX and the follow-
ing code number XX.
Error Messages
Code Meaning
F00 00 No fault has occurred.
Overload
F01 00 Frequency inverter overloaded.
02 Frequency inverter overloaded (60 s), check load behavior.
F01
03 Short-term overload (1 s), check motor and application parameters.
Heat Sink
00 Heat sink temperature too high, check cooling and fan.
F02
01 Temperature sensor defective or ambient temperature too low.
Table "Error Messages" continued on next page.
