18.4.2 Volume Flow and Pressure
The parameterization of the factors
Nominal Volumetric Flow 397 and Nominal
Pressure
398 is necessary if the matching actual values Volumetric flow 285 and
Pressure 286 are used to monitor the drive. The conversion is done using the electri-
cal control parameters.
Volume Flow 285 and Pressure 286 are referred to the Ef-
fective Current
214 in the case of the sensor-less control methods. In the case of the
field-oriented control methods, they are referred to the torque-forming current com-
ponent
Isq 216.
Volume Flow and Pressure
No. Description Function
285 Volumetric Flow Calculated volume flow with the unit m
3
/h
286 Pressure
Pressure calculated according to the characteris-
tic with the unit kPa
